The units have high sensitive thermal imaging sensor. This provides Polaris with the perfect detail recognition even when the thermal contrast of the surroundings is low - during the snow, dust, smoke, fog, haze, and other atmospheric obscurants.
IP67 Waterproof Rated
IP67 waterproof-rated for protection from heavy rainfall, snow or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 1 meter of water for up to 30 minutes.
High Definition Image
Built-in Precise Laser Rangefinder Reading Up To 1km
Polaris is capable of accurately measuring distance to objects up to 1000 meters away. The Integrated, precise laser rangefinder provides three modes -single time measurement mode, scanning mode and high-humidity mode.
-Wavelength: 905 nm
-Max. measuring range: 1000 m
-Measurement accuracy :± 1m
1200G High Shock Resistance
Polaris features high shock resistance and can be used with rifled hunting weapon for such cartridges as 9.3х64, .30-06, .300, .375. etc, and with smooth-bore and airsoft weapon.
Wifi and on-board recording
Built-in Wi-Fi module allows you to connect the Polaris with mobile units which enables you to receive footage in the real-time mode and save the image/video captured by the device.32 Gb of internal memory provides enough space for recording and taking photos of exciting moments.
Extreme Detection Range
A powerful F35 /1.1 or F50/1.1 objective lens combined with a highly-sensitive thermal imaging sensor provides exceptional detection capabilities.
5 Optional Reticle Types
6 Adjustable Color Palettes
The 6-color palette enhances viewing in varying conditions.
Long lasting operation time
Polaris gives out long lasting operation time.External sources, such as power banks power bank with high-capacity is also capable of increasing the total operation time. 2 pcs of 18650 batteries meet the hunting needs of one night.
Picture-in-picture displays a X2 image at the top-center of the overall field of view for precise zooming on an object of interest.
Selectable reticle
A full complement of digitally displayed reticle solutions ensures quick target acquisition and a richly contrasting sight picture.
Choose from an array of reticle patterns, colors and brightness settings.
5 types of zeroing parameters memorization
Polaris has the function of saving five user's zeroing profiles in the memory (for different types of weapons or ammunition), in each case a different reticle can be applied. In addition, each profile allows zeroing at five different distances. Zoom zeroing support ensures particular zeroing precision.
High image frequency
Due to the high image frequency, it is comfortable to use thermal camera dynamically (during rapid moving of observer or object of observation).
User-Friendly interface
Polaris is designed with ease-of-operation in mind. User feedback has resulted in the most friendly interface to date, complete with an easy-to-read, icon-driven, alpha-numeric status bar at the bottom of the display. Internal menu items and options are also displayed on a contrasting gradient substrate so you can keep an eye on settings without losing sight of your objective.
Polaris Technical Data Sheet
Model
635R Pro
635RL Pro
650R Pro
650RL Pro
Detector
Type
Uncooled Vox
Resolution
640X512
Frame rate
50Hz
Pixel
12μm
Spectral range
8~14μm
NETD
≤ 25mk
Optical Characteristics
Objective lens
35mm/F1.0
50mm/1.1
Magnification
1.5x
2.2x
FOV
12.6°x10°
8.8°x7°
Close-up range
5m
Dioptre adjustment
-5D-4D
Functions
Zoom
2x/4x/PIP
Palette
6 optional(can be customized)
Start up time
Less than 5 seconds
Image enhancement
DDE
Contrast and brightness
AGC
Online update
Both code and GUI resources
Display
Type
OLED
Resolution
1024×768
External video
WIFI
Storage
32G
Power Supply
Battery
2x18650
External power supply
5V micro USB
Working time with battery
6h
Physical Characteristics
Weight without battery
623g
693g
665g
720g
Size
178*76*83mm
178*76*100mm
188*76*83mm
188*76*100mm
Environmental Compatibility
Water proof
IP67
Operating temperature
-20℃-50℃
Storage temperature
-40℃-60℃
Laser Rangefinder (Optional)
Safety class for laser equipment
according to IEC 60825-1:2014
